Cardboard Bolt Boxes
The Roe Group offers cardboard bolt boxes, waxed conical tubes specifically designed for accurately positioning holding down bolts in concrete foundations. A reliable and easy-to-use solution from our Stanchion Base Products range.
| Approx Diam | ||||
| Code | Length (mm) | Top | Bottom | Std Pack |
| CB1 | 229mm | 70 | 20 | 10 |
| CB2 | 305mm | 92 | 20 | 10 |
| CB3 | 380mm | 108 | 25 | 10 |
| CB4 | 457mm | 114 | 30 | 10 |
| CB5 | 534mm | 118 | 30 | 10 |
| CB6 | 610mm | 133 | 30 | 10 |
